Ultrasonic Liquid Flow Sensor Housings

Designed for small-pipe ultrasonic meters, liquid-flow sensors and sealed measurement modules, these custom-molded components combine functional geometry with production-ready part design. The molding plan is developed around accurate acoustic-path and sensor positioning, smooth, consistent internal flow channels, and reliable sealing and protected electronic interfaces. Resin selection, gate location, parting lines and inspection points are matched to the mating parts, operating environment and expected production volume.

Accurate Acoustic-Path and Sensor Positioning
Smooth, Consistent Internal Flow Channels
Application-Specific Resin Selection
DFM, Tooling and Repeat Production

Product Overview

Custom housings for ultrasonic liquid-flow sensor assemblies

JingZhan develops moulded covers, bases and locating components for customer-designed ultrasonic liquid-flow and bubble-sensing assemblies. The manufacturing review connects the housing with the sensing elements, cable exit and mating parts. The scope is custom plastic-component supply; sensing electronics, calibration and finished-sensor performance are separately defined.

Blue sensor housing cover sample with cable leads viewed from the front
Sensor assembly sample showing the cover face, perimeter and cable exit. Electronics and calibration are separate project scopes.

DESIGN AND MANUFACTURING

Key processing requirements

Control the sensing-element interface

Identify the features that position or support the sensing elements. Where wall geometry or a contact surface affects acoustic coupling, supply the required dimensions and acceptance method. Housing dimensions alone do not establish flow-measurement accuracy.

Review the complete enclosure

Provide the cover, base, gasket and fastening arrangement together. Check locating features, rim contact and cable routing using representative mating parts, not only isolated drawing dimensions.

Define the exposure conditions

Confirm temperature, cleaning agents, moisture exposure and any actual liquid-contact surfaces. Select the resin grade against these conditions and the required stiffness, colour and assembly method.

Keep moulding marks off critical areas

Review gates, parting lines, ejectors and venting around the locating and sealing features. Agree flash, distortion and visible-surface limits before trial approval, then check them by an appropriate fixture or inspection method.

Blue cover and black base component samples shown separately
Cover and base examples showing the relationship between the enclosure and internal locating features.

TECHNICAL SPECIFICATIONS

Parameters agreed for your part

Custom-manufacturing options, not common measured values for every pictured part.
Parameter Project specification
Component scope Custom sensor covers, bases, locating parts and related moulded assembly components.
Material options PC, ABS, PC/ABS, PBT or another approved grade reviewed against service conditions.
Geometry and dimensions Customer-defined 2D/3D data, with critical sensing-element interfaces identified.
Assembly interfaces Cover-to-base fit, fastening points, cable exits and any gasket or potting interface.
Tolerance and measurement Feature-specific drawing requirements and agreed dimensional/fixture checks.
Surface acceptance Colour reference, functional contact areas and permitted gate, flash and ejector marks.
Tool configuration Cavity count, inserts and maintenance access reviewed with the part geometry and demand.
Delivery condition Protected packing, revision and lot identification, plus scoped inspection documents.
JingZhan CNC machining equipment in the toolroom
Company toolroom equipment supports machining of project-specific mould inserts and interfaces.

PRODUCTION AND REPEAT SUPPLY

Equipment, lead time and order planning

The proposed route combines CNC/EDM toolmaking, suitable insert finishing and injection moulding. JingZhan's listed machining, EDM, moulding and dimensional/vision inspection equipment provides project-specific process options. Press selection follows the shot volume, projected area, tool construction and resin; checks reference the agreed locating and enclosure datums.

Indicative planning only. Final MOQ and lead time are confirmed for the project.
Planning item Basis for quotation
DFM review Indicative 3–5 working days after complete drawings and requirements.
New tooling Indicative 4–6 weeks to first mould trial after tool-design approval and commercial release; corrections and customer validation are additional.
Order quantities Initial quotation-planning basis: a 500-piece pilot or 1,000-piece repeat batch per part number, resin and colour, subject to project quotation.
Repeat orders Indicative 10–15 working days after materials and the production slot are confirmed. Customer qualification, special processing and transit are additional.
JingZhan dimensional inspection equipment
Inspection resources are assigned to suitable features and agreed measurement methods.

Keep repeat orders on an approved baseline

Approve the drawing revision, resin grade, colour sample and mating assembly before repeat releases. Define startup and in-process checks for the critical locating and enclosure features. Record relevant tool maintenance and review insert, resin or process changes before the affected batch is supplied.

Tooling investment is quoted separately from the piece price. Share annual demand and release quantities so cavity count, procurement and batch cost can be reviewed together.

RELATED APPLICATIONS

Where these components can be used

Custom housings integrated into small-tube ultrasonic liquid-flow sensing equipment.

Enclosure and locating components for customer-developed bubble-detection assemblies.

Related sensing-module housings used in industrial, laboratory or medical-equipment development, subject to the final system requirements.

Blue and black sensor housing assembly photographed at an angle
Assembled housing sample showing the side profile, support features and cover-to-base relationship.

Flow range, tube compatibility, acoustic performance, ingress protection and medical suitability belong to the specified completed assembly and its validation. No universal accuracy, pressure, temperature or IP rating is assigned to the photographed housing examples.

Discuss your drawing and supply requirements. Send CAD, resin preference, critical features, annual demand and release quantity. Contact our engineering team →

Technical Specifications

Process Custom precision plastic injection molding
Product Group Ultrasonic Liquid Flow Sensor Housings
Typical Applications small-pipe ultrasonic meters, liquid-flow sensors and sealed measurement modules
Material Options PBT, PPS, PA, PC/ABS and other engineering resins selected for sealing, electronics protection and fluid compatibility
Engineering Focus accurate acoustic-path and sensor positioning, smooth, consistent internal flow channels, and reliable sealing and protected electronic interfaces
Project Support DFM review, mold design, mold trials, assembly validation and repeat production
Customization Geometry, color, texture, resin, inserts and packaging can be developed to project requirements
