Designed for contact-lens mold halves, lens-support bases and coordinated packaging components, these custom-molded components combine functional geometry with production-ready part design. The molding plan is developed around controlled lens and mold-surface geometry, repeatable centering and base alignment, and clean part release without damage to critical surfaces. Resin selection, gate location, parting lines and inspection points are matched to the mating parts, operating environment and expected production volume.

Controlled Lens and Mold-Surface Geometry
Repeatable Centering and Base Alignment
Application-Specific Resin Selection
DFM, Tooling and Repeat Production

Product Overview

Mould halves and bases for repeatable lens production

JingZhan develops custom moulded lens-forming components, support bases and related plastic parts for contact-lens manufacturing projects. The engineering review connects the forming surface with the locating rim, handling features and mating part. These photographs show component examples, not finished contact lenses ready for wear.

Clear and white moulded lens-forming and base component samples
Related moulded halves and bases showing the mating rim, support and locating details.

DESIGN AND MANUFACTURING

Key processing requirements

Protect the functional surface

Identify the lens-forming or support area on the drawing. Agree permitted flow marks, gate locations, ejector contact and handling marks before tooling. A polished appearance alone does not establish optical performance.

Control the mating geometry

Review the two halves or the base and its mating component together. Define datums, alignment, rim contact and any closing requirement, using the customer's intended assembly and inspection method.

Match material to the process

Confirm the resin grade against the intended lens chemistry, temperature and release process. Shrinkage, stiffness and surface behaviour must be reviewed for the selected grade rather than assumed from its polymer name.

Keep cavities consistent

Plan filling, cooling, venting and demoulding for the cavity arrangement. Check the approved critical features by cavity during trials, and use a controlled sample baseline for repeat orders.

White round moulded base component samples on a grey background
Base-component examples photographed from different sides to show the wall and rim geometry.

TECHNICAL SPECIFICATIONS

Parameters agreed for your part

Custom-manufacturing options, not common measured values for every pictured part.
Parameter Project specification
Component scope Lens-forming mould halves, support bases, locating parts and coordinated plastic components.
Resin selection Customer-specified PP, PS, COC/COP or another reviewed grade; suitability depends on the manufacturing process.
Forming geometry Custom surface and rim data supplied in approved 2D/3D drawings.
Critical interfaces Mating rim, alignment features, support diameter and customer-defined handling features.
Tolerance and measurement Feature-specific requirements and agreed dimensional or surface-inspection methods.
Surface acceptance Defined functional areas, approved reference samples and permitted moulding marks.
Tooling and identification Cavity layout, insert construction and cavity identification reviewed with forecast demand.
Delivery condition Packing, cleanliness expectations, lot identification and documents agreed at quotation.
JingZhan toolmaking workshop with manufacturing equipment
Company workshop photograph. Tool construction and finishing are selected for the approved component design.

PRODUCTION AND REPEAT SUPPLY

Equipment, lead time and order planning

The proposed route combines CNC/EDM toolmaking, suitable insert finishing and injection moulding. JingZhan's equipment list includes CNC and EDM resources, moulding presses and dimensional/vision inspection equipment. Machine size, cavity count and the checking route are selected for the actual tool, resin and agreed critical surfaces.

Indicative planning only. Final MOQ and lead time are confirmed for the project.
Planning item Basis for quotation
DFM review Indicative 3–5 working days after complete drawings and requirements.
New tooling Indicative 6–8 weeks to first mould trial after tool-design approval and commercial release; corrections and customer validation are additional.
Order quantities Initial quotation-planning basis: a 500-piece pilot or 1,000-piece repeat batch per part number, resin and colour, subject to project quotation.
Repeat orders Indicative 10–15 working days after materials and the production slot are confirmed. Customer qualification, special processing and transit are additional.
JingZhan CNC machining equipment in the toolroom
Toolroom equipment supports insert machining and project-specific mould development.

Keep repeat orders on an approved baseline

Freeze the drawing revision, resin grade, appearance sample and acceptance method before repeat release. Record cavity checks and tool maintenance affecting the forming or locating features. Review resin, insert or process changes before the affected batch is supplied.

Tooling investment is quoted separately from the piece price. Share annual demand and release quantities so cavity count, procurement and batch cost can be reviewed together.

RELATED APPLICATIONS

Where these components can be used

Mould halves and supports for customer-developed contact-lens forming processes.

Locating and transfer components used within lens-manufacturing assemblies.

Related bases and handling parts supplied as coordinated component sets.

Row of white moulded round base and cap components
Related round moulded components illustrating rim and support features; final lens-forming geometry is drawing-specific.

Finished-lens performance, biological evaluation and any required cleaning or sterilization validation belong to the defined customer process and final product. They are not inferred from a component photograph.

Discuss your drawing and supply requirements. Send CAD, resin preference, critical features, annual demand and release quantity. Contact our engineering team →

Technical Specifications

Process Custom precision plastic injection molding
Product Group Contact Lens Molded Lenses and Base Components
Typical Applications contact-lens mold halves, lens-support bases and coordinated packaging components
Material Options customer-specified transparent, packaging or engineering resins selected for lens handling, sealing and release requirements
Engineering Focus controlled lens and mold-surface geometry, repeatable centering and base alignment, and clean part release without damage to critical surfaces
Project Support DFM review, mold design, mold trials, assembly validation and repeat production
Customization Geometry, color, texture, resin, inserts and packaging can be developed to project requirements
