Fluid Filter Frames and Cartridge Components

These fluid filter frames and cartridge components are engineered for fluid-filter skeletons, mesh supports and cartridge assembly kits, from early DFM review through repeat production. The molding plan is developed around open flow area with reliable mesh support, stable cartridge diameter and end interfaces, and controlled ribs that resist collapse without blocking flow. Resin selection, gate location, parting lines and inspection points are matched to the mating parts, operating environment and expected production volume.

Open Flow Area with Reliable Mesh Support
Stable Cartridge Diameter and End Interfaces
Application-Specific Resin Selection
DFM, Tooling and Repeat Production

Product Overview

Moulded frames and cartridge parts designed for repeatable assembly

JingZhan develops custom plastic filter frames, support cages, end components and related cartridge parts from approved drawings. The engineering review connects the support structure with the filter medium, mating housing and assembly process. These are custom component examples, not a standard filter supplied with one shared filtration or pressure rating.

Black moulded fluid-filter frame photographed from the side
Filter-frame example showing the support windows, end profile and axial locating features.

DESIGN AND MANUFACTURING

Key processing requirements

Support the medium without unwanted interference

Define the medium, its seating surfaces and the required support geometry. Review ribs, windows and edge conditions with the actual assembly so permitted moulding marks do not obstruct the intended interfaces.

Control the mating features together

Provide housing, end-cap and any seal-interface data. Agree datums, engagement depths and checking fixtures for the completed cartridge rather than treating each part as an isolated dimension set.

Keep slender features stable

Assess wall balance, core support, filling and cooling around long ribs or thin cage features. Review distortion and demoulding before tool release, then check trial parts against the agreed support and fit requirements.

Specify the fluid and assembly conditions

Confirm the actual fluid, temperature, cleaning exposure and joining method. Select the resin grade and any inserts against that scope. Mesh, media, bonding and final assembly are included only when expressly quoted.

Three black filter-frame and cartridge component examples
Different frame and cartridge geometries illustrating variations in length, ribs and end interfaces.

TECHNICAL SPECIFICATIONS

Parameters agreed for your part

Custom-manufacturing options, not common measured values for every pictured part.
Parameter Project specification
Component scope Filter frames, support cages, cartridge bases, end components and related moulded parts.
Material options PP, PA, PBT, POM or another listed resin, reviewed by grade and service conditions.
Dimensions and layout Custom 2D/3D data, including rib layout, windows and medium-support features.
Critical interfaces Housing fit, medium seating, end engagement and any customer-defined sealing surfaces.
Tolerance and inspection Feature-specific drawing requirements and agreed fixtures or dimensional checks.
Surface acceptance Flash limits, edge condition, colour and permitted gate or ejector marks.
Tooling plan Cavity count, core arrangement, inserts and maintenance access reviewed during DFM.
Supply and documents Plastic parts or defined assemblies, protected packing, revision and scoped lot records.
JingZhan CNC machining equipment in the toolroom
Company toolroom resources support custom core, insert and mould development.

PRODUCTION AND REPEAT SUPPLY

Equipment, lead time and order planning

The proposed route combines CNC/EDM toolmaking and injection moulding, with suitable finishing of the specified support and mating surfaces. JingZhan's equipment list provides machining, EDM, moulding and dimensional/vision inspection options. Press and core arrangements are selected for the part length, projected area, shot volume and approved resin.

Indicative planning only. Final MOQ and lead time are confirmed for the project.
Planning item Basis for quotation
DFM review Indicative 3–5 working days after complete drawings and requirements.
New tooling Indicative 4–6 weeks to first mould trial after tool-design approval and commercial release; corrections and customer validation are additional.
Order quantities Initial quotation-planning basis: a 500-piece pilot or 1,000-piece repeat batch per part number, resin and colour, subject to project quotation.
Repeat orders Indicative 10–15 working days after materials and the production slot are confirmed. Customer qualification, special processing and transit are additional.
JingZhan dimensional inspection equipment
Dimensional checks are assigned to the approved support, locating and mating features.

Keep repeat orders on an approved baseline

Approve the component revision, resin grade, mating samples and inspection method before repeat releases. Define startup checks for the support and engagement features. Review repairs or changes affecting cores, ribs, inserts or resin before supplying the affected production batch.

Tooling investment is quoted separately from the piece price. Share annual demand and release quantities so cavity count, procurement and batch cost can be reviewed together.

RELATED APPLICATIONS

Where these components can be used

Support structures and cartridge components for customer-designed fluid-filtration assemblies.

Moulded cages and end components coordinated with specified mesh or filter media.

Related cartridge parts integrated into industrial or automotive fluid-system development, subject to the complete assembly requirements.

Three filter-cartridge examples with support frames and mesh sections
Cartridge assembly references. Mesh, media and assembly supply are confirmed separately in the project quotation.

Filtration efficiency, micron rating, pressure drop, flow capacity and durability depend on the defined medium and completed assembly. They are not assigned to a plastic support frame from its photograph, and must be agreed and validated for the project.

Discuss your drawing and supply requirements. Send CAD, resin preference, critical features, annual demand and release quantity. Contact our engineering team →

Technical Specifications

Process Custom precision plastic injection molding
Product Group Fluid Filter Frames and Cartridge Components
Typical Applications fluid-filter skeletons, mesh supports and cartridge assembly kits
Material Options PP, PA, PBT, ABS and other chemical-resistant engineering resins selected for the fluid, temperature and pressure range
Engineering Focus open flow area with reliable mesh support, stable cartridge diameter and end interfaces, and controlled ribs that resist collapse without blocking flow
Project Support DFM review, mold design, mold trials, assembly validation and repeat production
Customization Geometry, color, texture, resin, inserts and packaging can be developed to project requirements
